Headlamps single halogen (Not available with (ZR7) Chrome Appearance Package.)
Bumpers front and rear painted Black with step-pad (Deleted when (ZR7) Chrome Appearance Package is ordered.)
Glass Solar-Ray light-tinted all windows
Wheels 4 - 16 x 6.5 (40.6 cm x 16.5 cm) steel includes Gray center caps and steel spare
Tires rear LT245/75R16E all-season blackwall
Tire spare LT245/75R16 all-season blackwall located at rear underbody of vehicle
Mirrors outside manual Black
Wipers front intermittent wet-arm with pulse washers
Grille Black composite with single rectangular halogen headlamps (Not available with (ZR7) Chrome Appearance Package.)
Door swing-out passenger-side 60/40 split
Cargo tie-downs 6 D-ring attachments on cargo area floor (Not available with (Y3H) Paratransit Package (5BV) Upfitter electrical provisions (5L3) interior trim panel or (ZP6) 5-passenger Savana Crew Van.)
Tow/haul mode selector instrument panel-mounted
Power outlet 120-volt
Door locks power with lock-out protection (Included with (ZQ2) convenience Package. NOTE: Does not include (ATG) Remote Keyless Entry. (ATG) Remote Keyless Entry must be ordered separately.)
Visors driver and front passenger cloth padded
Floor covering full-length Black rubberized-vinyl (Not available with (RFM) rear floor covering delete (5BV) Upfitter electrical or (PCH) Hotel Shuttle Package.)
Instrumentation analog with speedometer odometer with trip odometer fuel level voltmeter engine temperature and oil pressure
Oil life monitor
Air conditioning single-zone manual
Headliner cloth over driver and passenger
Seating arrangement driver and front passenger high-back buckets with head restraints and vinyl or cloth trim (Not available with (AJ3) driver-side only frontal air bag.)
Windows power (Included with (ZQ2) Convenience Package.)
Steering wheel steel sleeve column with theft-deterrent locking feature Black
Trim panels hinged rear side doors and hinged rear doors (Not available with (Y3H) Paratransit Package.)
Seats front bucket with vinyl trim and outboard head restraints includes inboard armrests. (Requires (**W) interior trim. Includes (DAA) driver and front passenger vinyl visors.)
Power outlets 2 auxiliary on engine console cover with covers 12-volt
Assist handles driver and right-front passenger
Cup holders 3 on the engine console cover
Theft-deterrent system vehicle PASS-Key III
Warning tones headlamp on and key-in-ignition
Driver Information Center includes fuel range average speed oil life tire pressure monitoring fuel used ice warning engine hours average fuel economy tachometer and maintenance reminders. Compass and outside temperature available if equipped.
Lighting interior with 4 dome lights 1 overhead and 3 LED's on cross members in cargo area includes defeat switch and door handle-activated switches
Console engine cover with open storage bin
Defogger side windows
Engine Vortec 4.8L V8 SFI (285 hp [212.5 kW] @ 5400 rpm 295 lb-ft of torque [398.3 N-m] @ 4600 rpm) (Includes external engine oil cooler. Reference the Engine/Axle page for availability.)
Body Standard
Suspension front independent with coil springs and stabilizer bar
Transmission oil cooler external (Deleted when (LWN) 2.8L Duramax Turbo Diesel engine is ordered.)
Exhaust aluminized stainless-steel muffler and tailpipe
Transmission 6-speed automatic heavy-duty electronically controlled with overdrive tow/haul mode and internal transmission oil cooler (Reference the Engine/Axle page for availability.)
Rear axle 3.42 ratio (Reference the Engine/Axle page for availability.)
Fuel tank capacity mid-frame and approximately 31 gallons (117.3L)
Suspension rear hypoid drive axle with multi-leaf springs
Brakes 4-wheel antilock 4-wheel disc
Alternator 105 amps (Not available with (Y3H) Paratransit Package or (LWN) 2.8L Duramax Turbo Diesel engine.)
Steering power
Rear wheel drive
Battery 600 cold-cranking amps maintenance-free with rundown protec
